Herma 400 - Menu 100 Basic data (Master encoder settings)

9
Operating instructions HERMA 400 O
PERATION (VIA THE HERMA 400 CONTROL)
3.28 US (130519) 107/154
9.8 Menu 100 Basic data
9.8.1 115 Master enc. transfer
This parameter will appear only if parameter 110 (available only for Technical Service) is set to „02
Master encoder“. With PWL2 only. this and the two following parameters are
for all application types
except for rigid beak, pivot beak and type 211.
The dead time of a unit (e.g. transverse transfer unit) can be determined and compensated with the
hel
p of this parameter, in conjunction with parameter 116.
Production: 
The normal setting for production, w
ithout determining the dead time.
Test speed low: 
Select this setting and label a product at slow test speed.
Test speed fast: 
Select this setting and label the same p
roduct at high test speed.
Dead time calculation: 
Select this setting to enter in parameter 116 the difference / the distance between the two labels
di
spensed above.
9.8.2 116 Master enc. transfer Label pos. difference
This parameter will appear only if parameter 110 (available only for Technical Service) is set to „02
Master encoder“ and parameter 115 is set to auf „Dead time calculation“. With PWL2 only.
Enter the difference / the distance in mm between the labels dispensed above (parameter 115). The
de
ad time determined will be entered in parameter 122 after pressing the
key.
9.8.3 120 Master encoder Pulses / revolution
This parameter will appear only if parameter 110 (available only for Technical Service) is set to „02
Master encoder“.
Adjusting the pulses/increments emitted per revolution of the master encoder. See the indication at
t
he master encoder.
Note: Entering a negative value here, e.g. -2000, wi
ll reverse the sense of rotation of the
master encoder.
9.8.4 121 Master encoder Distance / revolution
This parameter will appear only if parameter 110 (available only for Technical Service) is set to „02
Master encoder“.
Adjusting the distance of the web covered per revolution of the master encoder.
9.8.5 122 Master encoder Start compensation
This parameter will appear only if parameter 110 (available only for Technical Service) is set to „02
Master encoder“. With PWL2 only.
Setting the dead time of the start sensor in order
to compensate for the resulting delay. See also
parameter 116 (PWL3 required).
