3.28 US (130519) 23/154
4 Applicator description
In this chapter you will find an overview of the applicator HERMA 400 and its sub-assemblies.
Overview
For an overview of the applicator HERMA 400 see chapter 1, page 12.
4.1 Sub-assemblies
Risk of electric shock. 110-240 Volts may be present and could cause
electrocution. Disconnect all sources of supply and wait for five minutes
before opening the rear cover or touching the connector pins! If
components are worked on while the applicator is not disconnected from
mains this could cause electrocution.
Always disconnect mains before working on the sub-assemblies.
There are rotating parts at the applicator. Make sure to tie up long hair (if
required, wear a hair net) and avoid wide clothing. Your hair or your
clothes could get entangled in the applicator and lead to serious injuries.
Especially make sure to not reach into the area where the feed roller
draws in the web when machine is on!
Usually there are variants for the individual sub-assemblies, e.g. standard unwinder (also: „reel
holder“) or motorized unwinder (each with or without loop-type unwinder), standard or motorized
rewinder (also: „backing paper take-up unit“), label sensor FS03 or forked light barrier etc.
The variants used in your applicator you will take from the pictures, illustrations and descriptions in
the corresponding chapter. Due to the clear distinctions between the variants you will not be able to
confuse one variant with the other.
