3.28 US (130519) 73/154
5 Technical Data
Warning! This device may cause radio interference in residential areas; in such case the operating
company may be obliged to t
ake appropriate measures.
HERMA 400 applicators are factory-tested prior to shipment and ready to operate. They come with
basic adjustments.
The following specifications refer to
the applicator’s drive unit.
Power supply / Line voltage Wide range input
100V AC ... 240V AC ±10%,
50 Hz ... 60 Hz
Max. power consumption 400 W + n times 100W (n=number
of motorized winder units)
Leakage current, according to EN 60335-1 110VAC: <0.35 mA
150VAC: <0.5 mA
230VAC: <0.7 mA
Fuse protection in the applicator 2x T 3.15 A type TR5
Operating temperature range +32°F ... 104°F (+0°C ... +40°C)
Storage and transport temperature -4°F ... 176°F (-20°C ... +80°C)
Maximum installation elevation with nominal data 2.500 m above mean sea level
Maximum permissable relative humidity 35% ... 85%, free of condensation
Sound pressure level in ope
ration at working place max. 75dB(A)
Type of protection IP66
Output capability 250 mA (nominal), short circuit-
proof
, = maximum load over all
outputs
Safety class I; Class 2 peripherals may be
connected
Diameter label reel Standard: 12“ (300
mm)
Maximum: 16“ (400 mm, optional)
Core diameter Standard: 3“ (76 mm)
Constructionial variants For right-hand and left-hand
operation
Dimensions Customer-specific; see section 5.1
below for examples
