5
Technical Data Operating instructions HERMA 400
74/154 3.28 US (130519)
Further applicator data you can find on the type label on the cover of this manual.
Under extreme operational conditions, maybe e.g. with model HERMA 400
Pr
emium, above-mentioned ranges are subject to restrictions that cannot be
defined exactly. In case of an overload the applicator may switch off
automatically.
When connecting the applicator to an external control there are connectors available for inputs and
outputs. For the assignment of these optional connectors see the following sections.
Unused outputs must be insulated before putting into operation.
Weight Customer-specific; see section 5.1
below for examples
Winder system Sl
imLine
Max. reel width for reel diameter of 16’’: 12.6’’ (400 mm: 320 mm)
20’’: 7.8’’ (500 mm: 200 mm)
23.6’’: 6.3’’ (600 mm: 160 mm)
Max. unwinding speed for core diameter of 3’’ : 394 ft/min (120 m/min)
6’’ : 492 ft/min (150 m/min)
