Herma 400 - Right-Hand Applicator with Dispensing Plate with Spring-Loaded Roller, 75° Angular; Left-Hand Applicator with Dispensing Plate with Spring-Loaded Roller, 75° Angular

6
Transport, installation, storage and connection
Operating instructions HERMA 400
88/154 3.28 US (130519)
6.5.5 Right-hand applicator with dispensing plate with spring-loaded roller, 75° angu-
lar
6.5.6 Left-hand applicator with dispensing plate with spring-loaded roller, 75° angular
Further to these standard layouts there are variants when using the SlimLine winder system
(motorized unwinder and rewinder, with or without loop-type unwinder), the arrangements of which
including web path is shown in the following illustrations.
O
I
I = Innenwicklung / inside winding
681300
O = Außenwicklung / outside winding
681300
0 = Außenwicklung / outside winding
I = Innenwicklung / inside winding
O
I
I = Innenwicklung / inside winding
681301
O = Außenwicklung / outside winding
681301
0 = Außenwicklung / outside winding
I = Innenwicklung / inside winding
