Operating instructions
HERMA 400 OPERATION (VIA THE HERMA 400 CONTROL)
3.28 US (130519) 123/154
03 Actual (large), Batch: Display of the actual number of produced products in large letters and the
batch size.
04 Left (large), Batch: Display of what is left to be produced in large letters and the batch size.
9.12.4 940 Alarm message after missing labels
With PWL2 only.
Error message SM148 will appear if the label sensor detected n missing labels in a row (n=1...7).
9.12.5 941 Alarm message after end of reel
If this parameter is set to On error message SM107 will appear in case of end of reel.
9.12.6 942 Alarm message after undefined web move
If this parameter is set to On error message SM141 will appear in case of undefined web movement
9.12.7 943 Alarm message after start sequ. too close
If this parameter is set to On error message SM163 will appear in case products fed with too little
distance to each other.
9.12.8 944 Monitoring quality
This parameter will appear only after activating the special function of „Quality monitoring“. With
PWL2 only.
With the help of this parameter you can determine the strictness of monitoring the quality of label
transport. Monitoring will be effected for the distance up to the „falling edge“, the label gap width as
well as the total distance including overfeed delay (stop delay). Tolerance can be determined with an
additional parameter. If tolerance is exceeded for one of these values a specific error message will be
generated. The folliowing settings are available:
00 Off:
Monitoring is deactivted.
01 High:
With this setting the values determined on manual feeding are used as reference values. Any deviation
of tolerance will lead to a standstill and a corresponding error message. Stop delay must not be
changed in this case.
READY F05
Actual:
000 p/min
Batch: 0000000 pcs
Menu
READY F05
Left:
000 p/min
Batch: 0000000 pcs
Menu
