4
Applicator description
Operating instructions HERMA 400
40/154 3.28 US (130519)
> D/E: Loosen screw 1.
Turn adjusting plate 2 to the left or to the right until label web passes below the brake plate
smoothly, but with perceptible resistance.
Tighten screw 1.
Cleaning
> F: Push brake plate towards direction a to disengage it and at the same time towards direction b to
loosen and fully retract it (G-I).
Clean brake plate. After cleaning push brake plate back to position and depress until it engages.
