Operating instructions
HERMA 400 APPLICATOR DESCRIPTION
3.28 US (130519) 63/154
Replacing the round belt
Risk of electric shock! Disconnect all sources of supply and wait for five
minutes before opening the rear cover or touching the connector pins!
Electrocution may occur.
Take the belt from tension pulley B, then from roller A and subsequently from roller C.
When remounting proceed in reverse order.
