8.1 Specifications and Standard Accessories
8.1.1 Specifications
Throughput: 128 tests per hour (simultaneous CM and ISE tests)
Number of incubator cells: CM 12, ISE 1
Incubation temperature: 98.6°F (37°C) (CM)
86°F (30°C) (ISE)
Incubation time: 1 to 6 minutes
Number of slides that can be loaded at a time: 20
Sampler:
Pipetting fluid volume: Below 50µL (automatic switching)
Dilution: Automatic dilution (dilution factor: max. 10)
Slide ejection: Automatic ejection (max. 100 slides into the disposal box)
Used tip ejection: Automatic ejection (into the disposal box)
Measurement wavelengths: 400 nm, 415 nm, 505 nm, 540 nm, 577 nm, 600 nm, 625 nm, 650 nm
Light source: Halogen lamp (6 V, 10 W)
Measurement precision: 0.0004 OD/5 minutes
Measurement accuracy: ± 0.005 OD (600 nm)
Display: 5.7 inch color touch panel
Warming up time: Approx. 10 minutes/77°F (25°C), approx. 20 minutes/59°F (15°C)
Environmental conditions:
Location: Indoor use
Illumination: Below 6,000 cd/m
2
(lux)
(Below 3,000 cd/m
2
(lux) when using the sample barcode reader)
Altitude: Up to 6,560 ft. (2,000 m)
Transient overvoltage category: II
Pollution degree: 2
Operating temperature: 59 to 89°F (15 to 32°C)
Operating humidity: 30 to 80% RH (no vapor condensation)
Storage and transportation conditions:
Temperature: 14 to 122°F (-10 to 50°C)
Humidity: 10 to 90% RH (no vapor condensation)
Electrical requirements:
Voltage limit: 100–240 V
Frequency: 50–60 Hz
Supply voltage fluctuations: ± 10%
Rated current: 2.5–1.1 A
Phase: Single
Type of protection against electrical shock: CLASS 1 EQUIPMENT
Sound level: Under 70 dB (includes beep sound)
Data transfer: RS232C interface (1 port), LAN (1 port), USB interface (1 port, bar code
reader only)
External dimensions: 18.5 (W) x 14.2 (D) x 16.5 (H) in. (470 (W) x 360 (D) x 420 (H) mm)
Weight: 53 lb. (24 kg)
Section 8: Specifications/Consumables
117
Element DC
Veterinary Chemistry Analyzer
