2.1 Component Names

Section 2: Component Names and Functions

Sampler Cover

Card Reader

Front Under Cover

Disposal Box

LCD Under Cover

LCD Touch Panel

Printer

Sample Rack

Incubator Cover

Spotting Part

Light Source Lamp

ISE Unit (inside)

(inside)

Slide Reader (inside)

Sampler

Incubator Cable

Element DC

Veterinary Chemistry Analyzer
