Heska Element DC - Printout Indications Table

Error Code
Error Description Reference Section Reference Page
W090, W097, W099 Data communication error 5.2.12 87
W110 No tip has been set 5.2.4 76
W112 No tip for the next test 5.2.4 76
W115, W116 Tip eject error 5.2.4 77
W120 Tip sensor error 5.2.4 77
W140 An ISE slide is loaded in incorrect direction 5.2.10 84
W141, W142 Errors related to ISE tests 5.2.11 85–86
W150, W160 Errors related to dilution 5.2.4 78
W170 No QC card has been read 5.2.9 84
W173 Slide reader cannot read slide information 5.2.3 76
W175 No slides have been set 5.2.10 84
W200 Errors related to sample barcode reader 5.2.12 87
W210 Sample rack setting error 5.2.13 88
W220 LAN communication error 5.2.12 87
W500–W503 Faulty fan 5.2.13 88
W5110 No paper 5.2.2 76
W5120 Wrong setting of printer head 5.2.2 76
5.1.2 Printout Indications Table
Printout Message
Description and status Solution
H Testing value exceeds the upper limit of the preset reference interval. -
L Testing value falls below the lower limit of the preset reference interval. -
> Testing value exceeds the upper limit of the measurement range. -
< Testing value falls below the lower limit of the measurement range. -
@
Testing value is out of the measurement range.
IMPORTANT
The testing value may NOT be accurate. Rerun the test.
-
+OR Testing value for ISE test exceeds the upper limit of the measurement range. Refer to Section 5.2.11
-OR Testing value for ISE test falls below the lower limit of the measurement range. Refer to Section 5.2.11
+,–, $
Temperature control error.
IMPORTANT
The testing value may NOT be accurate. Refer to the related troubleshooting
pages and rerun the test.
Refer to Section 5.2.7
*, ?
Fluctuation of light source intensity.
IMPORTANT
The testing value may NOT be accurate. Refer to the related troubleshooting
pages and rerun the test.
Refer to Section 5.2.5
63
