361
2. Input and measurement specications
-1. Basic specications
Number of input
channels
5 channels (voltage only)
Input terminals
Measurement target Voltage
Input type
All channels isolated
A/D resolution 16 bits
Maximum input
voltage
±100 V DC
Maximum channel-to-
channel voltage
300 V DC
Maximum rated
terminal-to-ground
voltage
300 V AC, DC (Measurement Category II)
Anticipated transient overvoltage: 2500 V
Input resistance 1 M
Allowable signal
source resistance
100
or less
Data refresh interval 1 ms, 2 ms, 5 ms, 10 ms, 20 ms, 50 ms, 100 ms, 200 ms, 500 ms, 1 s, 2 s, 5 s, 10 s
Digital lters
Power
supply
frequency
lter setting
Data refresh interval
1 ms 2 ms 5 ms 10 ms 20 ms 50 ms 100 ms 200 ms 500 ms 1 s 2 s 5 s 10 s
60 Hz 50 k 5.4 k 2.6 k 1.0 k 400 200 100 60 60 10 5 5 5
50 Hz 50 k 5.4 k 2.6 k 1.0 k 400 200 100 50 50 10 5 5 5
Unit: Hz
-2. Accuracy specications
Accuracy guarantee
conditions
Product warranty duration 1 year
Accuracy guarantee duration
after adjustment made by Hioki
1 year
Accuracy guarantee temperature
and humidity range
Warm-up time At least 30 min. after turning on the module
