4 Individual remote controls
PC-ARF
TCGB0106 rev.0 - 12/2014
103
4
• Check Interval
When the motion sensor detects an absence at selected check interval time, the function “If absent” will be executed. The
interval can be selected from 30, 60, 90 120 or 180 minutes.
(The default setting is 30 minutes.)
Setting of motion sensor
1 Press “
” (menu). Select “Motion Sensor Setting” from the
menu by pressing “
” or “ ” and press “OK”.
Menu
Motion Sensor Setting
Total Heat Exchanger SET
VENTI
Louver Open/Close
02
/
03
Louver Setting
15:10(Fri)
ENT
TN.SEL.
OK
OK
OK
2 “Motion Sensor Setting” is displayed. The highlighted item is
shifted to “Sensor”, “If absent” and “Check interval” by press-
ing “
” or “ ”.
To set “Sensor”, go to step 3. To set “If absent”, go directly to step
5. To set “Check interval”, go directly to step 7.
Motion Sensor Setting
Sensor
ON
If absent
Running
Check interval
30MIN
ENT
TN.SEL. ADJ
OK
OK
3 Press “ ” or “ ” and select “Sensor”.
Motion Sensor Setting
Sensor
ON
If absent
Running
Check interval
30MIN
ENT
TN.SEL. ADJ
OK
OK
4 The display is switched “ON” and “OFF” in order by pressing “
” or “ ” and change the setting.
If other settings are not required, go directly to step 9.
Motion Sensor Setting
Sensor
ON
If absent
Running
Check interval
30MIN
ENT
TN.SEL. ADJ
OK
OK
5 Press “ ” or “ ” and select “If absent”.
Motion Sensor Setting
Sensor
ON
If absent
Running
Check interval
30MIN
ENT
TN.SEL. ADJ
OK
OK
6 The display is switched “Running”, “Stand-by” and “Stop” in
order by pressing “
” or “ ” and change the setting.
If other settings are not required, go directly to step 9.
Motion Sensor Setting
Sensor
ON
If absent
Running
Check interval
30MIN
ENT
TN.SEL. ADJ
OK
OK
To Next Page
