3 Features and benets
Individual remote controls
TCGB0106 rev.0 - 12/2014
3939
3
3.1.4 PC-LH3(A/B)
PC-LH3(A/B): Wireless remote control
• Wireless remote control that requires no wiring and provides simple one-touch operation.
• Same remote control for all the indoor units.
• Each indoor unit has its own receiver.
• Up to 16 indoor units can be controlled simultaneously by one wireless remote control in case that all units are installed
in the same room. To do this, the indoor units must be interconnected by means of control cables.
• Specic function “Identifying of indoor units installed side by side” for those indoor units which are installed very close
and each one needs to be independent. This function enables to operate individually each unit without interfering other
unit’s operation.
NOTE
• PC-LH3A is available for combination with the receiver kits (PC-ALH, PC-ALHN, PC-ALHC, PC-ALHD and PC-ALHZ).
• PC-LH3B is available for combination with the receiver kits (PC-ALH3, PC-ALHZF and PC-ALHP1) and the indoor units
which are supported HIGH2 fan speed mode.
• The fan speed setting “HIGH2” is not indicated on PC-LH3A.
Wireless receiver kit
PC-LH3(A/B) requires the installation of a wireless receiver kit in order to let the indoor unit receive the signal from the wire-
less remote controller. The list of all the available wireless receiver kits for each indoor unit is shown below:
Receiver kit Indoor unit Wireless remote control Installation type Image
PC-ALH
RCI-FSN3Ei PC-LH3A
On the panel
PC-ALHN
PC-ALHC RCIM-FSN3 PC-LH3A
PC-ALHD RCD-FSN2 PC-LH3A
PC-ALH3
RCI-FSN3
RCI-FSN3Ek
PC-LH3B
PC-ALHP1 RPC-FSN3 PC-LH3B
PC-ALHZ
RCI-FSN3Ei
RCIM-FSN3E
RCD-FSN2
RPC-FSN2
RPI-FSN(3/4)(P)E
RPIM-FSN4E(-DU)
RPK-FSN(H)2M
RPF(I)-FSN2E
PC-LH3A
On the wall
PC-ALHZF
RCI-FSN3
RCI-FSN3Ek
RPK-FSN(H)3M
RPC-FSN3
PC-LH3B
NOTE
RPK-FSN(H)3M indoor unit comes with a built-in wireless receiver kit in the panel. Use PC-LH3B wireless remote controller
in combination with this indoor unit.
