7.1.2.4 General data
Hardware Specications
Item Specications
Power supply 1~ 230 V ±10% 50 Hz
Consumption 4.5W (maximum)
Outer dimensions Width: 106 mm, Depth: 90 mm, Height: 58 mm
Weight 165 g
Assembling conditions Indoors (installation inside an enclosure with restricted access by a tool)
Ambient temperature 0~60 ºC
Humidity 20~85% (Without condensation)
Communication
RS485
Item Specications
Type Modbus RTU
Connector Serial Port RS485 (3 screw terminals)
Communication line Shielded twisted pair cable, with third wire (for the common), with polarity.
Communication system Half-duplex, multipoint serial connection
Communication method Non parity or odd/even parity selection. Data length: 8 bits – 1 stop bit
Baud rate transmission 19200/9600 Baud
Length Max. 1200 m according EIA-485
Ethernet
Item Specications
Type Modbus TCP
Connector Ethernet (RJ45)
Communication line Two twisted pair cable CAT5 or better (T-568A/T-568B)
Communication system Full-duplex
Length Max. 100 m according IEEE 802.3
H-LINK
Item Specications
Communication with Hitachi Air Conditioning series: SET-FREE, UTOPIA and CENTRIFUGAL systems
Communication line Twisted pair shielded cable, non-polarity
Communication system Half-duplex
Communication method Asynchronous
Speed of transmission 9600 Bauds
Length of wiring 1000 m maximum (total length of H-LINK I/O bus)
Maximum number of gateways 1 Gateway (HC-A8MB,HC-A64MB)/H-LINK SYSTEM
Maximum number of indoor units
HC-A64MB → up to 64 indoor units
HC-A8MB → up to 8 indoor units
7 Gateways for building management systems
HC-A(8/64)MB
TCGB0106 rev.0 - 12/2014
