9.1 Wall and stand mounted support for CSNET Manager LT/XT
9.1.1 Components list
Unpack the unit and check that:
• The package contains all the components (see next table).
• All components are in perfect condition.
Otherwise, contact the manufacturer.
Wall mounted support
Name Figure Quantity Comments
Wall support part 1 To be informed later. 1 Wall support part to be xed on CSNET Manager.
Wall support part 2 To be informed later. 1 Wall support part to be xed on the wall.
Screw
4 For xing the support device on the wall.
Plug
4 -
Instruction sheet
Wall support
1 Instructions for the installation work.
(*): All the data regarding Stand support are preliminary data, and therefore, they are subject to changes.
Stand mounted support
Name Figure Quantity Comments
Stand support base
1
Base for holding the stand support arm and the
CSNET Manager.
Stand support arm
Stand support part to be xed on CSNET Manager.
Screw
4 For xing the stand support arm on CSNET Manager.
Rear support screw
1 For xing the stand support base.
Instruction sheet
Stand support
1 Instructions for the installation work.
9 Control accessories
Wall and stand mounted support for CSNET Manager LT/XT
TCGB0106 rev.0 - 12/2014
748
