5.2.2.4 General data
Model PSC-A32MN
Outer Dimension
<W x H x D + (Built-in Part)>
140 × 120 × 22 + 52.7 (mm)
Net Weight 0.5 kg (approx.)
Installation Location Indoor
Installation Method
Wall built-in with
JIS switch box for 2 switches (with cover) (JIS C 8340)
Connected Indoor Units (Quantity) 160 (Max.)
Clock Accuracy ± 70 seconds/month (at normal temperature)
Ambient Temperature 5 ~ 35°C
Ambient Humidity 35 ~ 90% (No dew condensation)
Display 5.0” TFT colour liquid crystal display
Rated Power Supply 1ɸ, AC 100~240V, 50/60Hz
Electrical Power Consumption 20W (Max.)
5.2.2.5 Dimensional data
(Unit: mm)
25
80
55
250
170
71
90
83.5
46
Fixing hole
5 Centralised remote controls
PSC-A32MN
