6.1.5.8 Operation and conguration of packaged units
The following chapter will apply when the system has Packaged units. Remember that it is not possible to connect water
chillers and Packaged units in the same H-LINK communication line.
1
2
3
4
1 Area tree: Installation tree with the different areas dened by the user.
2 Units zone: Lists of all the indoor units with a basic state information.
3 Main options: Gives access to the installation data view (Package), the conguration of CSNET WEB, the Historical
Data and the Power Consumption.
4 HARC-WEB Status: Shows the current state of four HARCWEB connections, software functions enabled and if there
are automatic updates available.
