5.2.4.4 Service Menu
NOTE
This switch is for the serviceman only. Therefore do not use it.
If this switch is used and the service menu is indicated on the screen, tap “Back”. The screen will return to the menu.
Items Contents
Group Register
The connected indoor units are checked by the central station in the same H-LINK. This function is
used for the group or block registration of them.
Setting of control
patterns
Set the control pattern.
Main Unit Register
This function is used for the main unit registration in the each remote control group. (The main unit
is the only one (1) in the one (1) remote control group.) The control command is sent from the cen-
tral station to the main unit for the remote control group.
Sub Unit Register
This function is used for registration of the sub units except the main unit in the same remote control
group. In the case of using the remote control switches or the receiver kits as follows, the sub units
are registered automatically by the central station after the main unit registration.
• The remote control switches and the receiver kits which model names start from PC-A**.
• The remote control switches which model names start from PC-P**.
Display list of reg-
isters
Display the address of the Indoor Units which were registered in each group
Optional Function Set-
ting
This function is used for setting and changing of the optional functions for the air conditioners and
the central stations.
Air Conditioner,
Remote Control
Switch Setting
Set or change the optional function of the air conditioner and remote control switch.
Central Station
Setting
Set or change the operation mode or the color of the operation indicator or the central station.
Exception Setting of
Run/Stop Operation
The set group is “All Group Run (stop)”, “Block run (stop)” or when“All Groups (Blocks)”operate as
“Run(Stop)”, this operation is not accepted.
External Input/Output
Setting
There are 4 inputs and 2 outputs for external Input/Output function in the central station.
Button Setting
This function species each button to be shown/hidden.
This function also includes specication/setting for “one-tap operation” or “press and hold” operation.
Contact Information
Register
This function is used for editing the contents of contact information registration.
Memo Record and Browse the Test Run and Maintenance Informations
Restore Setting This function is used for restoring all the settings such as registered Groups (Blocks) and schedules.
Checking Connection
This function is used for checking of the connected indoor unit numbers in the same H-LINK.
When this function is used, the conrmation for the keeping of registered information such as the
group names, schedules, etc. will be indicated.
If “OK” is tapped, the connected indoor unit numbers are updated with keeping the registered infor-
mation. If “Cancel” is tapped, the setting of the central station is all restored.
Alarm History
This function is used for displaying the list of alarm history that occurred in the air conditioner and
the controller. (Maximum 100 records)
5 Centralised remote controls
PSC-A32MN
TCGB0106 rev.0 - 12/2014
349
5
