Hitachi PSC-A1T Technical Catalogue

4 Individual remote controls
PC-ART
TCGB0106 rev.0 - 12/2014
152
Step
No.
Indoor unit capacity indication
24 Indoor unit capacity.
J1 08
The indoor unit capacity is indicated as shown in the following table:
Indoor unit capacity code
Indication code
Equivalent capacity
in (HP)
06 0.8
08 1
10 1.3
13 1.5
14 1.8
16 2
18 2.3
20 2.5
26 3
32 4
40 5
48 6
64 8
80 10
25
Outdoor unit code:
“n” indicates the total number of indoor units.
J2 Fn
n = 1 ~ , 9, A, b, C, d, E, F, U
(10) (11) (12) (13) (14) (15) (16)
26
Refrigerant cycle number:
- J3: 01 ~ 16 (Refrigerant cycle number, congured with indoor unit DSW5 DipSwitch), decimal indication:
J3 01
27
Refrigerant cycle number:
- J4: 00 ~ 0F (Refrigerant cycle number, congured with indoor unit DSW5 DipSwitch), hexadecimal indica-
tion (16 numbers).
J4 00
Step
No.
Compressor pressure/frequency indicator
28 Indoor unit expansion valve opening.
L1 20
29
Outdoor unit MV1 expansion valve opening.
- For models with no expansion valve, the same value will appear on both MV2 and MV1
L2 99
30
Outdoor unit MV2 expansion valve opening.
- For models with no expansion valve, the same value will appear on both MV2 and MV1
L3 99
31
Outdoor unit MVB expansion valve opening.
- FXN only.
L4 00
Step
No.
Estimated electrical current indication
32
Compressor current.
- The total current is indicated when several compressors are running at once.
For the inverter compressor, the operating current from the primary side of the inverter is indicated.
P1 25
33 Go back to step 1, temperature indication.
