6 Building air conditioning controls
CSNET WEB (PSC-A160WEB1)
TCGB0106 rev.0 - 12/2014
450450
Displaying historical data
CSNET WEB allows you to save a history of data from all the machines connected to the H-Link.
It also displays the information in two different formats:
- Data in the form of a table, which can be exported in text format; and
- Data in graph format, which can be used to generate graphics for display.
To obtain historical data:
1 Select View data.
2 Select starting date (from).
3 Select end date (to).
4 Select unit to display.
5 Press the Get data button.
To download data to disk:
1 Select Download data.
2 Select starting date (from).
3 Select end date (to).
4 Press the Get data button.
To get data from le:
1 Select Load from le.
2 Press the Get data button.
Data can only be displayed in periods of one day, although they may be downloaded for greater time ranges. Select the
day to be displayed in the “Day” eld.
Operation of the graph
To change the display to graph mode, select the Graph tab on the display panel.
Select the conguration of the graph pressing on Congure....
