6 Building air conditioning controls
CSNET WEB (PSC-A160WEB1)
TCGB0106 rev.0 - 12/2014
513513
6
The table with all the functions and their description is shown below.
Table of functions
Pins Function Description
All OFF Rest
Indicates the type of installation (PA Packaged) If there is an alarm it shows the alarm code and
the units with this alarm.
2
Restore the network
conguration
Restore the IP address Mask and Gateway to the initial values of:
IP: 192.168.0.3
Mask: 255.255.255.0
Gateway: 192.168.0.1
3 Restore passwords Set the “User” password to “User” and the “Installer” password to “Installer”.
4 Restore conguration Deletes the conguration of the installation and restores the passwords as in the previous point.
5
Notication of the IP
address
Shows the IP address and the CSNET WEB port.
6 Information on units Shows the number of indoor and outdoor units recognized by CSNET WEB.
7
Central Station
compatibility
It enables the compatibility with central stations.
CSNET WEB has always priority so if a unit is set as central, Central Station will not be able to
modify the state of the unit. The same happens with remote sensor not congured option.
CAUTION
All units should be controlled by a Central Station, otherwise it will appear a communication alarm.
8 Set Packaged units Set units as Packaged. Value 0 means that units are Packaged.
