6 Building air conditioning controls
CSNET Manager LT/XT
TCGB0106 rev.0 - 12/2014
580580
Auto save conguration
The chapter “6.2.4.5 Local software conguration” shows how to access the software settings. The power consumption
function allows you to generate automatically a detailed report of the daily consumption of the installation.
To activate this option:
- Mark the selection box.
- Indicate the folder in which you want to save the le. The button to the right of the text window opens the navigation
window so that you can select the folder.
- Select the type of power consumption:
Month: Each day stores on a monthly le the values accumulated for the units since the rst day of the month.
Day: Each day stores on a monthly le the values of the power consumption of the current day.
- Selecting single le option it will also store in the folder a unique le with the power consumption. This le will have
the power consumption of each day registered.
- Including power meter data adds a column with energy values.
The auto save operates every day at 00:00. It stores a monthly le with the monthly accumulated or the daily power
consumption.
If the Single le option is activated, it will also store the daily power consumption in the single le.
File name is m1_YYYYMM.txt. YYYY means the year and MM the month.
For the single le, the name is power_log.txt for Package.
• File format
The le format saved has different columns separated by the tab character. The meaning of those columns for the packaged
le is:
Year Month Day CS Port OU IU Location %OU %System
In case of including power meter data, the le format is:
Year Month Day CS Port OU IU Location %OU %System Energy
In the case of manual saving, a row is added at the beginning with the meaning of each eld, but this does not occur when
automatically saving.
The automatic save must be selected from the “6.2.4.5 Local software conguration” section as explained earlier.
The Save to le button permits the data to be manually saved.
