Hitachi PSC-A1T Technical Catalogue

Switch conguration for the previous example
Step
number
Action
7 segments
(display)
Remarks
For “id” 14:
1 Press SW4 for 3 seconds
id
Conguration mode selected
2 Press SW4
OO
Id selection (IU No.) From 0 to 15
(By pushing SW5 ▲ & SW6 ▼)
3 Press SW4
oU
Refrigerant cycle address
4 Press SW4
--00
Refrigerant cycle address selection from 0 to 63
(By pushing SW5 ▲ & SW6 ▼)
5 Press SW4
iU
Indoor unit address
6 Press SW4
--00
Indoor unit address selection from 0 to 63
(By pushing SW5 ▲ & SW6 ▼)
For “id” from 01 to 13 repeat steps 1 to 6
7 Press SW4 for 3 seconds
id
Conguration mode selected
8 Press SW4
OO01
Id selection (IU No.) from 0 to 15
(By pushing SW5 ▲ & SW6 ▼)
9 Press SW4
oU
Refrigerant cycle address
10 Press SW4
--00
Refrigerant cycle address selection from 0 to 63
(By pushing SW5 ▲ & SW6 ▼)
11 Press SW4
iU
Indoor unit address
12 Press SW4
--01
Indoor unit address selection from 0 to 63
(By pushing SW5 ▲ & SW6 ▼)
For “id” 14:
85 Press SW4 for 3 seconds
id
Conguration mode selected
86 Press SW4
OO14
Id selection (IU No.) from 0 to 15
(By pushing SW5 ▲ & SW6 ▼)
87 Press SW4
oU
Refrigerant cycle address
88 Press SW4
--12
Refrigerant cycle address selection from 0 to 63
(By pushing SW5 ▲ & SW6 ▼)
89 Press SW4
iU
Indoor unit address
90 Press SW4
--02
Indoor unit address selection from 0 to 63
(By pushing SW5 ▲ & SW6 ▼)
For “id” 15:
91 Press SW4 for 3 seconds
id
Conguration mode selected
92 Press SW4
OO15
Id selection (IU No.) from 0 to 15 by pushing
SW5 ▲ or SW6 ▼
93 Press SW4
oU
Refrigerant cycle address
94 Press SW4
--25
Refrigerant cycle address selection from 0 to 63
(By pushing SW5 ▲ & SW6 ▼)
95 Press SW4
iU
Indoor unit address
96 Press SW4
--61
Indoor unit address selection from 0 to 63
(By pushing SW5 ▲ & SW6 ▼)
7 Gateways for building management systems
HC-A16KNX
TCGB0106 rev.0 - 12/2014
644644
