7 Gateways for building management systems
KNX001
TCGB0106 rev.0 - 12/2014
667667
7
Files
KNX001 saves the conguration of each project in the following les:
<TYPE>.INI A text le that saves information regarding the connection and other special adjustments.
<TYPE>.DAT A text le with values separated by tabs, with information corresponding to the signals.
<TYPE>.HGT A binary le created from the les mentioned above. It is the one really sent to KNX001.
These les, once installation is completed, must be backed-up for future modications. It is not permitted to obtain
the KNX001 conguration, only Upload is permitted, not Download.
In the le <TYPE>.INI the following adjustment variables are found:
[<TYPE>]
TmConnectCSNET_s=10, Timeout for connection with CSNET WEB (seconds)
TmResponseCSNET_s=2, Timeout for CSNET WEB response (seconds)
[EIB]
tS_ChekEIB=60, Rate of EIB electronic supervision (seconds)
tMS_WaitUpdate=2000, Timeout for Read request responses (milisec)
tMS_WaitInConect=6000, Timeout in Connect status (milisec)
NOTE
Do not touch these variables if you are not sure how they work. Their maladjustment may cause KNX001 not to operate or to operate
incorrectly.
