Making Eyeline Measurements
(HP 83480A Option 001 only)
This section includes a description of the HP Eyeline software, and
its installation and usage when used with the HP 83480-series digital
communications analyzer. The benets achieved by using HP Eyeline
software are:
 continuous traces to show individual waveforms that make up an eye
diagram, referred to as \eyeline" traces.
 noise reduction in eye diagrams through trace averaging.
 analysis
of specic
data patterns
that lead
to
mask
violations
,
referred
to
as
\error trace
capture".
