The Instrument at a Glance
Menu and Key Conventions
A softkey such as
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Sweep Triggered Freerun
oers you a choice of
functions. In this case you could choose Triggered by pressing the softkey
until Triggered is highlighted, or choose Freerun by pressing the softkey until
Freerun is highlighted. A choices softkey will be indicated throughout this
manual as:
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Sweep Triggered Freerun
Triggered.
When some softkeys, such as
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Eye Height
, are pressed the rst time,a
measurement will be made and the result will be provided. Some softkeys,
such as
NNNNNNNNNNNNNNNNNNNN
Offset
require the entry of a numeric value.To enter or change the
value, use the general purpose knob located below the front-panel Measure
section.
