Using the User Flatness
The following program interrogates the swept signal generator and
Correction Commands,
an HP 437B power meter for frequency and power information
Example Program 8
respectively. The swept signal generator is programmed to sweep
from 2 to 20 GHz, with frequency-correction pairs every 100 MHz
and
+5
dBm
leveled output power. For this example, we assume
that the path losses do not exceed 5
dBm
and that the HP 437B
power meter already has its power sensor’s calibration factors stored
in sensor data table 0. If another power meter is used, the power
sensor’s calibration factors will have to be stored in a look-up
table. Modify the program to suit your particular measurement
requirements. Up to 801 points may be entered in the user flatness
correction table with this program.
SCPI commands are used to set up the source parameters and enter
correction frequencies and data into the correction table.
!ASSIGN
THE ADDRESS TO THE SOURCE AND POWER METER
DIM
A$[5000],B$[5000]
ASSIGN @Source TO 719
ASSIGN
@Meter
TO
713
INTEGER Error-flag
ABORT 7
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
!SET
UP SOURCE
OUTPUT
QSource;"*RST"
OUTPUT
OSource;"FREQ:MODE
SWE;STAR
2 GHZ;STOP 20
GHZ"
OUTPUT
QSource;"SWEEP:TIME
200
MS”
OUTPUT
OSource;"POW:LEV
5 DBM;:INIT:CONT
ON"
OUTPUT
OSource;"*OPC?"
ENTER
OSource;Done
!SET
UP POWER METER
OUTPUT
OMeter;"PR"
OUTPUT
QMeter;"FA"
OUTPUT
QMeter;"TRO"
I
!ZERO
POWER METER
OUTPUT
OSource;"POW:STAT
OFF"
Zero-meter(OMeter,OSource,Error_flag)
IF Error-flag THEN
BEEP
CLEAR SCREEN
PRINT
"ERROR:METER
DID NOT COMPLETE ZEROING OPERATION!"
ELSE
I
!SET
UP CORRECTION FREQUENCIES IN USER FLATNESS CORRECTION TABLE
!OUTPUT
OSource;"CORR:FLAT
'I;
Start_freq=2
Stop_freq=20
Increment=1
N=(((Stop-freq-Start,freq)/Increment)+l)
Getting Started Programming
1-l
