Auto Fill Stop
Auto
Fill
Stop
Function Group
FREQUENCY, POWER
Menu Map
2,5
Description
This softkey is used in two locations: Fltness Menu and
List Menu. The operation is the same in both applications.
This softkey enables the entry of a stop frequency used to determine
the ending frequency of the automatic filling array. The array is not
created until either the increment value or the number of points is
assigned. The auto fill stop frequency does not affect the swept signal
generator stop frequency. When Auto Fill Stop is selected, the
active entry area indicates:
-->
Fill Stop: XXXXXXXXX MHz
where X represents a numeric value. Unless a previous entry was
made, the display indicates the swept signal generator maximum
frequency.
Programming Codes
SCPI: NONE, see Fltness Menu or List Menu
Analyzer: NONE
See Also
Fltness Menu, List Menu
“Optimizing Swept Signal Generator Performance” in Chapter 1
Operating and Programming Reference A-27
