HP 8360 B Series User Manual

RF Output
Output Power
Maximum Leveled
3
Standard
Option 006
HP 83620B, HP 83622B
+13
+13
HP 83623B
+17
+17
HP 83624B
+20
+17
HP 83630B
Output Frequencies < 20 GHz
+13
+13
Output Frequencies 1 20 GHz
+10
t-10
HP 83640B
Output Frequencies < 26.5 GHz
+10
i-10
Output Frequencies > 26.5 GHz
-l-6 i-6
HP 83650B
Output Frequencies < 26.5 GHz
i-10
t10
Output Frequencies 2 26.5 GHz and < 40 GHz
+5
t5
Output Frequencies 2 40 GHz
t2.5
t2.5
With attenuator (Option 001): Minimum settable output power is -110 dBm.
Maximum leveled output power is reduced by 1.5 dB to 20 GHz, 2.0 dB above
20 GHz, and 2.5 dB above 40 GHz.
Minimum Settable
Standard: -20 dBm
Option 001: -110 dBm
Resolution: 0.02 dB
Switching Time: (without attenuator change): 10 ms, typical
Temperature Stability: 0.01 dB/OC, typical
Typical Maximum Available Power
L HP83624EI
I
30
25
I
HP L?X+B
I
0.01 2.0 13.5 20 25.5 40 50
Frequency (Gttz)
3 Specification applies over the 0 to 35 “C temperature range (0 to 25 ‘C for output
frequencies > 20 GHz). Maximum leveled output power over the 35 to 55 ‘C
temperature range typically degrades by less than 2 dB.
2c-4 Specifications

HP 8360 B Series Specifications
