HP 8360 B Series User Manual

10. Select Auto Fill Start @ IGHz). Set the first frequency in
correction table to 2 GHz.
11. Auto Fill Stop @ @ ml. Set the last frequency in
correction table to 20 GHz.
12. Auto Fill Incr 0 @ @ (MHz). Set the frequency increment to
every 100 MHz from 2 to 20 GHz.
Setup Power Meter
13. Zero and calibrate the power meter/sensor.
14. Connect the power sensor to test port.
15. Enter and store in the power meter, the power sensor’s cal factors
for correction frequencies to be used.
Enter Correction Data into Array
16. Select Mtr Meas Menu Measure Corr All . The power meter
is now under swept signal generator control and is performing
the sequence of steps necessary to generate the correction
information at each frequency point.
If an HP-IB error message is displayed verify that the interface
connections are correct. Check the HP-IB address of the power
meter and ensure that it is the same address the swept signal
generator is using (address 13 is assumed). Refer to the menu
map 8, System, for the key sequence necessary to reach softkey
Meter Adrs .
Enable User Flatness Correction
17. When the operation is complete, (a message is displayed) the
flatness correction array is ready to be applied to your setup.
18. Disconnect the power meter/sensor.
19. On the swept signal generator, press (POWER LEVEL) (TJ m.
Where
n=P
0 max
-P path loss for maximum leveled power at the test
port.
20. To save the swept signal generator parameters including the
correction table in an internal register, press (SAVE) 0.
(n = number 1 through 8).
Getting Started Advanced 1-45
