2. Reconnect the transceivers and cables to the port blades:
NOTE:
The ports and cables used in trunking groups must meet specific requirements. For a list of
these requirements, refer to the
HP StorageWorks Fabric OS 6.2.x administrator guide.
a. Position one of the transceivers so that the key is oriented correctly to the port and insert the
transceiver into the port until it is firmly seated and the latching mechanism clicks.
b. Select the cable that corresponds to the port and position it so that the key (the ridge on one
side of the cable connector) is aligned with the slot in the transceiver; then, insert the cable
into the transceiver until the latching mechanism clicks.
c. Repeat step 2a and step 2b for the remaining ports.
TIP:
Do not route cables in front of the air exhaust vent (located on the upper port side of
the chassis).
d. Organize the cables as required.
Replacing DC04 SAN Director field-replaceable units (FRUs)204
