14 Lift handles (optional) The lift handles can be used to lift a frame into or out of a rack.
15 Removable device bay shelves The removable device bay shelves can be used to partition the device
bays for full or half-height components.
16 Reusable zip ties for power supplies (single-
phase frames only)
Reusable zip ties that help prevent single-phase power cables from
disconnecting from the power connectors.
17 CAT6A cable or DAC cable or SFP+ DAC
cable ,
CAT6A or DAC cable or SFP+ cable for cabling frames, depending on the
frame link module ordered.
2.00 ft (60.96 cm) cable—Used for cabling two consecutive frames.
10.00 ft (304.80 cm) cable—Used for cabling the top frame to the
bottom frame in a rack.
21.00 ft (640.08 cm) cable—Used for cabling management links
requiring long runs to the top of the rack.
18 HPE Synergy Start Here Poster The quick setup poster provides an overview of the installation process.
19 Installation instructions for compute
modules, options, and interconnects
The printed installation instructions for HPE Synergy components.
20 HPE Synergy 12000 Frame Rack Template The printed template for locating the positions of frames, rack rails, and
cage nuts in a rack.
ItemItem NameName DescriptionDescription
Quantity as ordered
Quantity and type as ordered
Not shown
3
3
3
1 3
3
3
3
1
2
3
Pallet contents 22

HP HPE Synergy 12000 Frame Specifications

General

Form Factor	Rack-mountable
Maximum Compute Modules	12
Management Module	HPE Synergy Composer
Cooling	Redundant fan modules
Power Supply	Redundant power supplies
Networking	HPE Synergy 12000 Frame Interconnect
Product Type	Blade Enclosure
Width	44.5 cm
Compliance	FCC, VCCI, BSMI, CCC, KCC, RoHS
Depth	36.25 in (92.08 cm)
