11 LINK port SFP+ connector that provides the following functions:
IMPORTANT:IMPORTANT:
Use supported SFP+ 10GbE DAC cables or transceivers for LINK port
connections. For more information, see the product QuickSpecs on the
Hewlett Packard Enterprise websiteHewlett Packard Enterprise website .
Provides high availability management network connectivity between:
LINK ports on two frame link modules in the same frame for a single frame
configuration
Frame link modules in different frames as part of a management network ring in
a multiframe configuration
Provides management ring (frame link topology) connectivity for automatic frame
discovery by HPE OneView.
12 MGMT port SFP+ connector that provides the following functions:
IMPORTANT:IMPORTANT:
Use supported SFP+ DAC cables or transceivers for MGMT port connections.
For more information, see the product QuickSpecs on the Hewlett PackardHewlett Packard
Enterprise websiteEnterprise website.
IMPORTANT:IMPORTANT:
The transceiver or cable used must match the port speed of the switch used
for management network connectivity.
Provides a management uplink to the management network.
10GbE or 1GbE based on the cable or transceiver used.
ItemItem DescriptionDescription FunctionFunction
