2 QSFP28 uplink port LEDs If the port is in 40GbE or 100GbE mode, only the leftmost LED lights up
when linked.
The four LEDs above each port correspond to the 10/25GbE or
8Gb/16Gb/32Gb FC channels of the port. The LEDs display one of four
modes:
Ethernet ID mode:
Solid green = The port is configured as an Uplink port.
Solid orange = The port is configured as a Stacking Link port.
Solid magenta = Configured as a Mirror to port.
Off = The port is not configured as an Ethernet port.
PID mode:
Solid green = The port is configured for Ethernet.
Solid orange = The port is configured for Fibre Channel.
Solid red = error.
Off = The port is not configured.
Link/Activity mode:
Solid green =
10Gb Ethernet link without activity
Flashing green =
10Gb Ethernet activity
Solid orange =
25Gb Ethernet link without activity
8Gb FC link without activity
Flashing orange =
25Gb Ethernet link with activity
8Gb FC link with activity
Solid magenta =
40Gb Ethernet link without activity
16Gb FC link without activity
Flashing magenta =
40Gb Ethernet link with activity
16Gb FC link with activity
Solid cyan =
100Gb Ethernet link without activity
32Gb FC link without activity
Flashing cyan =
100Gb Ethernet link with activity
32Gb FC link with activity
Off = No link or not configured
Fibre Channel (FC) ID mode:
Solid green = Logged into Attached Switch.
Solid orange = Not logged into Attached Switch.
Off = The port is not configured as an FC port.
To switch between the LED modes, press the Mode button.
