3 SFP+ Image Streamer port
LEDs
Left LEDLeft LED
Link/Activity mode:
Off = No Link
Solid green = Ethernet linked at 10Gb
PID:
Off = Not configured
Solid blue = Port ID
Solid green = Configured for Ethernet
Solid red = Error
Ethernet:
Off = Not Ethernet
Solid green = Configured for Ethernet
Fibre Channel:
Always off
Right LEDRight LED
Link/Activity mode:
Off = No activity
Flashing green = Activity at 10Gb
PID:
Always off
Ethernet:
Always off
Fibre Channel:
Always off
4 Fibre Channel (FC) mode
LED
Solid green = FC mode is selected.
5 Ethernet mode LED Solid green = Ethernet mode is selected.
6 PID mode LED Solid green = PID mode is selected.
7 Link/Activity mode LED Solid green = Link/Activity mode is selected.
8 Health LED Solid green = Normal
Flashing amber = There is a fault condition
Flashing red = Critical fault detected
Solid red = No power present
9 Mode button Press and hold the Mode button for more than 5 seconds to reset.
Solid green = There are four LEDs that indicate the operating mode for the
Port LEDs. The operating mode is selected by pressing the Mode button on
the front panel. The LED mode state determines which of the four Mode
LEDs is lit.
10 UID LED Solid blue = Activated
Flashing blue = Firmware upgrade in progress
Off = Deactivated
ItemItem DescriptionDescription StatusStatus
