223

[RouterB-Serial2/1/0] ip address 10.0.0.2 8

# Enable PPP encapsulation on the interface.

[RouterB-Serial2/1/0] link-protocol ppp

[RouterB-Serial2/1/0] quit

# Configure an IP address for interface Loopback 1.

[RouterB] interface loopback 1

[RouterB-Loopback1] ip address 40.0.0.1 32

[RouterB-Loopback1] quit

# Configure OSPF.

[RouterB] ospf

[RouterB-ospf-1] area 0

[RouterB-ospf-1-area-0.0.0.0] network 10.0.0.0 0.255.255.255

[RouterB-ospf-1-area-0.0.0.0] network 20.0.0.0 0.255.255.255

[RouterB-ospf-1-area-0.0.0.0] network 40.0.0.0 0.0.0.0

[RouterB-ospf-1-area-0.0.0.0] quit

[RouterB-ospf-1] import-route direct

Dynamic route backup for bundle DDR configuration example

Network requirements

As shown in Figure 69, Router A and Router B are directly connected through their serial interfaces. They

are also connected to the ISDN through their ISDN BRI interfaces. The telephone number of Router B is

8810010. The telephone number of Router B is 8810052.

Enable dynamic route backup on Router A to monitor network segment 30.0.0.0/8 connected to Router

Figure 69 Network diagram

Configuration procedure

1. Configure Router A:

# Create dialer group 1 and configure a dial rule for it.

<RouterA> system-view

[RouterA] dialer-group 1 rule ip permit

Create a local user userb for Router B, and configure the service type as PPP.

[RouterA] local-user userb class network

[RouterA-luser-network-userb] password simple userb
