HP MSR Router Series

60
[Router-luser-network-user1] service-type ppp
[Router-luser-network-user1] quit
# Configure an IPv6 prefix authorized to the user in the ISP domain.
[Router] domain system
[Router-isp-system] authorization-attribute ipv6-prefix 2003:: 64
[Router-isp-system] quit
Verifying the configuration
# Display PPP user information on GigabitEthernet 1/0/1.
[Router] display ppp access-user interface gigabitethernet 1/0/1
Interface Username MAC address IP address IPv6 address
VA0 user1 0000-5e08-9d00 - 2003::9CBC:3898:0:605
PPPoE server IPv6 address assignment through DHCPv6
configuration example
Network requirements
As shown in Figure 16, configure the PPPoE server to assign an IPv6 address to the host through DHCPv6.
Figure 16 Network diagram
Configuration procedure
# Create interface Virtual-Template 10.
<Router> system-view
[Router] interface virtual-template 10
# Configure interface Virtual-Template 10 to use PAP to authenticate the peer.
[Router-Virtual-Template10] ppp authentication-mode pap domain system
# Configure an IPv6 address for interface Virtual-Template 10.
[Router-Virtual-Template10] ipv6 address 3001::1 64
# Enable interface Virtual-Template 10 to advertise RA messages.
[Router-Virtual-Template10] undo ipv6 nd ra halt
# Configure the host to use the DHCPv6 protocol to obtain IPv6 addresses.
[Router-Virtual-Template10] ipv6 nd autoconfig managed-address-flag
# Enable the DHCPv6 server feature.
[Router-Virtual-Template10] ipv6 dhcp select server
[Router-Virtual-Template10] quit
# Enable the PPPoE sever on GigabitEthernet 1/0/1, and bind the interface to interface Virtual-Template
10.
[Router] interface gigabitethernet 1/0/1
[Router-GigabitEthernet1/0/1] pppoe-server bind virtual-template 10
