HP MSR Router Series User Manual

26
• Fragments the large packets into small fragments.
• Adds the fragments to the queues along with the voice packets.
Figure 2 LFI
To configure LFI:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter VT interface, MP-group
interface, or dialer interface view.
interface { dialer | mp-group
| virtual-template }
mp-number
N/A
3. Enable LFI.
ppp mp lfi enable
By default, LFI is disabled.
Disabling LFI also removes the
user-configured settings of the
maximum LFI fragment delay and
size.
4. Set the maximum LFI fragment
transmission delay and the
maximum LFI fragment size (in
bytes).
• ppp mp lfi
delay-per-frag time
• ppp mp lfi size-per-frag
size
By default, the maximum LFI
fragment transmission delay is 10
ms, and the maximum LFI fragment
size is the expected bandwidth of
the interface times the maximum
delay divided by 8.
Displaying and maintaining PPP and MP
Execute display commands in any view and reset commands in user view.
Task Command
Display information about PPP access users.
display ppp access-user { interface interface-type
interface-number [ count ] | ip-address ip-address |
ipv6-address ipv6-address | username user-name }
Display PPP address pools. display ip pool [ pool-name ] [ group group-name ]
Display IPHC statistics.
display ppp compression iphc { rtp | tcp } [ interface
interface-type interface-number ]
Voice packet
Large packet
Output queue
WFQ
Traffic
classifying
Fragmentation
WFQ
