204

[RouterC-luser-network-usera] password simple usera

[RouterC-luser-network-usera] service-type ppp

[RouterC-luser-network-usera] quit

# Configure an IP address for interface Dialer 0.

[RouterC] interface dialer 0

[RouterC-Dialer0] ip address 122.1.1.2 255.255.255.0

# Enable bundle DDR on the interface.

[RouterC-Dialer0] dialer bundle enable

# Specify the host name of the remote router allowed to call in.

[RouterC-Dialer0] dialer peer-name usera

# Associate the interface with dialer group 1.

[RouterC-Dialer0] dialer-group 1

# Configure the dial string for calling Router A.

[RouterC-Dialer0] dialer number 8810048

# Configure PAP authentication on the interface.

[RouterC-Dialer0] ppp authentication-mode pap

[RouterC-Dialer0] ppp pap local-user userc password simple userc

[RouterC-Dialer0] quit

# Assign the interface to dialer bundle 0.

[RouterC] interface bri 2/4/0

[RouterC-Bri2/4/0] dialer bundle-member 0

# Enable PPP encapsulation on the interface.

[RouterC-Bri2/4/0] link-protocol ppp

# Configure PAP authentication on the interface.

[RouterC-Bri2/4/0] ppp authentication-mode pap

[RouterC-Bri2/4/0] ppp pap local-user userc password simple userc

Verifying the configuration

# Verify that Router A can successfully ping Router B and Router C.

# Verify that Router B and Router C cannot ping each other.

MP for DDR configuration example

Network requirements

As shown in Figure 61, two ISDN BRI interfaces on Router A and an ISDN PRI interface on Router B are

connected across ISDN.

Configure Router A to call Router B by using bundle DDR, and configure Router B to call Router A by using

traditional DDR. In addition, implement traffic distribution for the two interfaces on Router A by setting

load thresholds.
