[Router-dhcp-pool-pool1] quit

# Create a PPPoE user.

[Router] local-user user1 class network

[Router-luser-network-user1] password simple pass1

[Router-luser-network-user1] service-type ppp

[Router-luser-network-user1] quit

Verifying the configuration

# Log in to the router by using username user1 and password pass1.

# Display information about IP addresses assigned by the DHCP server.

[Router] display dhcp server ip-in-use

IP address Client identifier/ Lease expiration Type

Hardware address

1.1.1.2 3030-3030-2e30-3030- Unlimited Auto(C)

662e-3030-3033-2d45-

7468-6572-6e65-74

The output shows that the router has assigned an IP address to the host.

PPPoE server IP address assignment through a remote DHCP

server configuration example

Network requirements

As shown in Figure 14, configure the PPPoE server as a DHCP relay agent to relay an IP address from the

DHCP server to the host.

Figure 14 Network diagram

Configuration procedure

1. Configure Router A as the PPPoE server:

# Configure interface Virtual-Template 10 to use PAP for authentication and use a DHCP address

pool for IP address assignment.

<RouterA> system-view

[RouterA] interface virtual-template 10

[RouterA-Virtual-Template10] ppp authentication-mode pap

[RouterA-Virtual-Template10] remote address pool pool1

# Specify an IP address for Virtual-Template 10.

[RouterA-Virtual-Template10] ip address 1.1.1.1 24

[RouterA-Virtual-Template10] quit

# Enable the PPPoE server on GigabitEthernet 1/0/1, and bind the interface to Virtual-Template

10.

[RouterA] interface gigabitethernet 1/0/1
