HP MSR Router Series User Manual

27
Task Command
Display information about VT interfaces.
display interface [ virtual-template [ interface-number ] ]
[ brief [ description | down ] ]
Display information about VA interfaces on a
VT interface.
display interface [ virtual-access [ interface-number ] ] [ brief
[ description | down ] ]
Display information about one or all MP-group
interfaces.
display interface [ mp-group [ interface-number ] ] [ brief
[ description | down ] ]
Display MP information. display ppp mp [ interface interface-type interface-number ]
Clear IPHC statistics.
reset ppp compression iphc [ rtp | tcp ] [ interface
interface-type interface-number ]
Log off a PPP user.
reset ppp access-user { ip-address ip-address [ vpn-instance
vpn-instance-name ] | ipv6-address ipv6-address
[ vpn-instance vpn-instance-name ] | username user-name }
Clear the statistics for VA interfaces. reset counters interface [ virtual-access [ interface-number ] ]
Clear the statistics for MP-group interfaces. reset counters interface [ mp-group [ interface-number ] ]
PPP and MP configuration examples
One-way PAP authentication configuration example
Network requirements
As shown in Figure 3, configure Router A to authenticate Router B by using PAP, but Router B not to
authenticate Router A.
Figure 3 Network diagram
Configuration procedure
1. Configure Router A:
# Create a user account for Router B.
<RouterA> system-view
[RouterA] local-user userb class network
# Set a password for the user account.
[RouterA-luser-network-userb] password simple passb
# Set the service type of the user account to PPP.
[RouterA-luser-network-userb] service-type ppp
[RouterA-luser-network-userb] quit
# Enable PPP encapsulation on Serial 2/1/0. By default, an interface uses PPP encapsulation.
[RouterA] interface serial 2/1/0
[RouterA-Serial2/1/0] link-protocol ppp
# Set the authentication mode to PAP.
