HP MSR Router Series User Manual

55
Task Command
Display summary information for a PPPoE
session.
display pppoe-client session summary [ dial-bundle-number
number ]
Display the protocol packet statistics for a PPPoE
session.
display pppoe-client session packet [ dial-bundle-number
number ]
Clear the protocol packet statistics for a PPPoE
session.
reset pppoe-client session packet [ dial-bundle-number
number ]
PPPoE configuration examples
PPPoE server configuration example
Network requirements
As shown in Figure 12, Host A and Host B run PPPoE client dialup software. The PPPoE server on the router
performs local authentication and assigns IP addresses to the clients.
Figure 12 Network diagram
Configuration procedure
# Create a PPPoE user.
<Router> system-view
[Router] local-user user1 class network
[Router-luser-network-user1] password simple pass1
[Router-luser-network-user1] service-type ppp
[Router-luser-network-user1] quit
# Configure interface Virtual-Template 1 to use CHAP for authentication and use a PPP address pool for
IP address assignment.
[Router] interface virtual-template 1
[Router-Virtual-Template1] ppp authentication-mode chap domain system
[Router-Virtual-Template1] ppp chap user user1
[Router-Virtual-Template1] remote address pool 1
[Router-Virtual-Template1] ip address 1.1.1.1 255.0.0.0
[Router-Virtual-Template1] quit
# Configure a PPP address pool that contains nine assignable IP addresses.
[Router] ip pool 1 1.1.1.2 1.1.1.10
