HP MSR Router Series

61
[Router-GigabitEthernet1/0/1] quit
# Configure DHCPv6 address pool 1 with network 3001::/32.
[Router] ipv6 dhcp pool pool1
[Router-dhcp6-pool-pool1] network 3001::/32
[Router-dhcp6-pool-pool1] quit
# Configure a PPPoE user.
[Router] local-user user1 class network
[Router-luser-network-user1] password simple pass1
[Router-luser-network-user1] service-type ppp
[Router-luser-network-user1] quit
# Configure an IPv6 pool attribute authorized to the user in the ISP domain.
[Router] domain system
[Router-isp-system] authorization-attribute ipv6-pool pool1
[Router-isp-system] quit
Verifying the configuration
# Display PPP user information on GigabitEthernet 1/0/1.
[Router] display ppp access-user interface gigabitethernet 1/0/1
Interface Username MAC address IP address IPv6 address
VA0 user1 0000-5e08-9d00 - 3001::2
Example for configuring PPPoE server IPv6 address assignment
through prefix delegation by DHCPv6
Network requirements
As shown in Figure 17, configure the PPPoE server to assign a prefix to Router A through DHCPv6. Router
A then assigns the prefix to the host for it to generate an IPv6 address.
Figure 17 Network diagram
Configuration procedure
# Create interface Virtual-Template 10.
<RouterB> system-view
[RouterB] interface virtual-template 10
# Configure interface Virtual-Template 10 to use PAP to authenticate the peer.
[RouterB-Virtual-Template10] ppp authentication-mode pap domain system
# Configure an IPv6 address for interface Virtual-Template 10.
[RouterB-Virtual-Template10] ipv6 address 2001::1 64
# Enable interface Virtual-Template 10 to advertise RA messages.
[RouterB-Virtual-Template10] undo ipv6 nd ra halt
