• The IPsec tunnel interfaces of the IPsec tunnel are configured with proper IPsec profiles.
• The expected IKE SA and IPsec SAs are established between the local security gateway and
the peer gateway. Use the display ike sa command to view the status the IKE SA and the
IPsec SAs.
To configure an IPsec tunnel interface:
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Create a tunnel interface
and enter its view.
interface tunnel
number
By default, no tunnel interface
exists on the device.
3. Assign a private IPv4
address to the tunnel
interface.
ip address
ip-address { mask |
mask-length } [
sub
]
By default, no private IPv4
address is assigned to a tunnel
interface.
4. Set the tunnel mode of
the tunnel interface to
IPsec over IPv4.
tunnel-protocol ipsec ipv4
N/A
5. Specify the source
address or interface of
the tunnel interface.
source
{ ip-address | interface-type
interface-number }
By default, no source address or
interface is specified for a tunnel
interface.
If you specify an interface, the
tunnel interface will take the
primary IP address of the source
interface.
6. Specify the destination
address of the tunnel
interface.
destination
ip-address
Optional for an IKE negotiation
responder, and required for an
IKE negotiation initiator.
By default, no tunnel destination
address is configured.
7. Apply an IPsec profile to
the tunnel interface.
ipsec profile
profile-name
The IPsec profile must have
been created and have not been
applied to any DVPN tunnel
interface.
For more information about commands interface tunnel, tunnel-protocol, source and destination,
see HPE FlexNetwork MSR Router Series Comware 5 Layer 3—IP Services Commands Reference.
An IPsec profile cannot be applied to both an IPsec tunnel interface and a DVPN tunnel interface
simultaneously.
An IPsec tunnel interface can reference only one IPsec profile.
Apply an IPsec profile to only one IPsec tunnel interface. Although an IPsec profile can be applied to
multiple IPsec tunnel interfaces, it takes effect only on the IPsec tunnel interface that goes up first.
Enabling packet information pre-extraction on the IPsec
tunnel interface
Because packets that an IPsec tunnel interface passes to a physical interface are encapsulated, the
QoS module cannot obtain the 5-tuple (source IP, destination IP, source port, destination port, and
protocol) of the original packets. To address this problem, enable packet information pre-extraction
on the tunnel interface.
