HPE FlexNetwork MSR Series Comware 5 Security Configuration Guide

445
Step Command Remarks
3. Configure HABP to operate
in client mode.
undo habp server
Optional.
HABP operates in client mode by
default.
The VLAN to which an HABP
client belongs must be the same
as that specified on the HABP
server for transmitting HABP
packets.
4. Specify the VLAN to which
the HABP client belongs.
habp client vlan
vlan-id
Optional.
By default, an HABP client
belongs to VLAN 1.
Displaying and maintaining HABP
Task Command Remarks
Display HABP configuration
information.
display habp
[
|
{
begin
|
exclude
|
include
}
regular-expression ]
Available in any view.
Display HABP MAC address table
entries.
display habp table
[
|
{
begin
|
exclude
|
include
}
regular-expression ]
Available in any view.
Display HABP packet statistics.
display habp traffic
[
|
{
begin
|
exclude
|
include
}
regular-expression ]
Available in any view.
HABP configuration example
Network requirements
As shown in Figure 145, the device is attached with access devices Switch A and Switch B. 802.1X
authentication is configured on the device for central authentication and management of users (Host
A through Host D).
For communication between Switch A and Switch B, enable HABP server on the device, enable
HABP client on Switch A and Switch B, and specify VLAN 1 for HABP packets.
Configure the HABP server to send HABP request packets to the HABP clients in VLAN 1 at an
interval of 50 seconds.
