HPE FlexNetwork MSR Series Comware 5 Security Configuration Guide

119
Displaying and maintaining MAC authentication
Task Command Remarks
Display MAC authentication
information.
display mac-authentication
[
interface
interface-list ] [
|
{
begin
|
exclude
|
include
}
regular-expression ]
Available in any view.
Clear MAC authentication
statistics.
reset mac-authentication
statistics
[
interface
interface-list ]
Available in user view.
MAC authentication configuration examples
Local MAC authentication configuration example
Network requirements
In the network in Figure 47, perform local MAC authentication on port GigabitEthernet 1/1 to control
Internet access.
• All users belong to domain aabbcc.net.
• Local users use their MAC address as the username and password for MAC authentication.
The MAC addresses are hyphen separated and in lower case.
• The access device detects whether a user has gone offline every 180 seconds. When a user
fails authentication, the device does not authenticate the user within 180 seconds.
Figure 47 Network diagram
Configuration procedure
# Add a local user account, set both the username and password to 00-e0-fc-12-34-56, the MAC
address of the user host, and enable LAN access service for the account.
<Device> system-view
[Device] local-user 00-e0-fc-12-34-56
[Device-luser-00-e0-fc-12-34-56] password simple 00-e0-fc-12-34-56
[Device-luser-00-e0-fc-12-34-56] service-type lan-access
[Device-luser-00-e0-fc-12-34-56] quit
# Configure ISP domain aabbcc.net to perform local authentication for LAN access users.
[Device] domain aabbcc.net
[Device-isp-aabbcc.net] authentication lan-access local
[Device-isp-aabbcc.net] quit
# Enable MAC authentication globally.
[Device] mac-authentication
# Enable MAC authentication on port GigabitEthernet 1/1.
[Device] mac-authentication interface gigabitethernet 1/1
