HPE FlexNetwork MSR Series Comware 5 Security Configuration Guide

422
Task Command Remarks
Display configuration information
about one or all attack protection
policies.
display attack-defense policy
[ policy-number ] [
|
{
begin
|
exclude
|
include
} regular-expression ]
Available in any view.
Display information about
blacklist entries.
display blacklist
{
all
|
ip
sour-address } [
|
{
begin
|
exclude
|
include
}
regular-expression ]
Available in any view.
Display the traffic statistics of an
interface.
display flow-statistics statistics interface
interface-type interface-number {
inbound
|
outbound
} [
|
{
begin
|
exclude
|
include
}
regular-expression ]
Available in any view.
Display the interface traffic
statistics based on IP addresses.
display flow-statistics statistics
{
destination-ip
dest-ip-address |
source-ip
src-ip-address } [
vpn-instance
vpn-instance-name ] [
|
{
begin
|
exclude
|
include
} regular-expression ]
Available in any view.
Clear attack protection statistics
information about an interface.
reset attack-defense statistics interface
interface-type interface-number
Available in user view.
Attack detection and protection configuration
examples
Attack protection functions on interfaces configuration
example
Network requirements
As shown in Figure 141, GigabitEthernet 1/1 is connected with the internal network, GigabitEthernet
1/2 is connected to the external network, and GigabitEthernet 1/3 is connected with an internal
server.
Protect internal hosts against Smurf attacks and scanning attacks from the external network. Protect
the internal server against SYN flood attacks from the external network. To meet the requirements,
perform the following configurations:
• On GigabitEthernet 1/2, configure Smurf attack protection and scanning attack protection,
enable the blacklist function for scanning attack protection, and set the connection rate
threshold that triggers the scanning attack protection to 4500 connections per second.
• On GigabitEthernet 1/3, configure SYN flood attack protection, so that the device drops
subsequent SYN packets when the SYN packet sending rate to a server constantly reaches or
exceeds 5000 packets per second, and permits SYN packets to be sent to the server again
when this rate drops below 1000 packets per second.
