110
Step Command Remarks
2. Set the EAD rule timer.
dot1x timer ead-timeout
ead-timeout-value
The default timer is 30 minutes.
Displaying and maintaining EAD fast deployment
Task Command Remarks
Display 802.1X session
information, statistics, or
configuration information.
display dot1x
[
sessions
|
statistics
]
[
interface
interface-list ] [
|
{
begin
|
exclude
|
include
}
regular-expression ]
Available in any view.
EAD fast deployment configuration example
Network requirements
As shown in Figure 46, the hosts on the intranet 192.168.1.0/24 are attached to port Ethernet 1/1 of
the network access device, and they use DHCP to obtain IP addresses.
Deploy EAD solution for the intranet so that all hosts must pass 802.1X authentication to access the
network.
To allow all intranet users to install and update 802.1X client program from a web server, configure
the following:
• Allow unauthenticated users to access the segment of 192.168.2.0/24, and to obtain IP address
on the segment of 192.168.1.0/24 through DHCP.
• Redirect unauthenticated users to a preconfigured web page when the users use a web
browser to access any external network except 192.168.2.0/24. The web page allows users to
download the 802.1X client program.
• Allow authenticated 802.1X users to access the network.
