Hypertherm Powermax 125 Service Manual

184 Powermax125 Service Manual 808070
9 – Power Supply Component Replacement
Figure 53
1
6
5
4
3
2
1 Power switch label
2 Perforation
3 Right half of label
4 Left half of label
5 RS-485 connector mounting hole
6 RS-485 connector

Hypertherm Powermax 125 Specifications

General

Output Current	30-125 A
Input Power	15.2 kW
Open Circuit Voltage	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Input Power Cable Length	10 ft (3 m)
Rated Output Current	125 A
Gas Type	Air or nitrogen
Cutting Capacity	1-1/4 inch (32 mm)
Pierce Capacity	1 inch (25 mm)
Input Voltage	200-600 V, 3-PH
Duty Cycle	100% @ 125 A
Certifications	CSA
Maximum Clean Cut Thickness	1-1/4 inch (32 mm)
Cooling Method	Fan-cooled
Torch Options	Hand
